Xtech 700 Watt Power Supply (20+4 PIN)

Description

Xtech 700 Watt Power Supply CS850XTK08

Specifications:

General

Brand: Xtech
Model: CS850XTK08 (commonly sold as Xtech 700W PSU)
Type: ATX desktop power supply unit
Rated power: 700W (reference output)
Standard: ATX 12V v2.2

Electrical (DC Output)

+12V rail: 45A
+5V rail: 38A
+3.3V rail: 28A
+5VSB: 2A
-12V: 0.8A
Input (AC)
Voltage: 115V / 230V (switch selectable)
Frequency: 47–63 Hz
Current: up to 5A (115V) / 3A (230V)

Connectors

20+4 pin ATX motherboard connector
P4 CPU connector
SATA power connectors (for SSD/HDD)
Molex (IDE) connectors
FDD connector (legacy)
Cooling
Fan: 1 × 80mm internal fan
Speed: ~2400 RPM
Cooling type: temperature-controlled airflow

Protection features

Over Voltage Protection (OVP)
Over Current Protection (OCP)
Over Power Protection (OPP)
Short Circuit Protection (SCP)

Physical

Form factor: ATX standard
Dimensions: ~150 × 100 × 85 mm
Weight: ~1.0–1.5 kg (varies by revision)
