Description
3ft Nexxt Patch Cord CAT5E Blue
Specifications
Cable category: CAT5e
Cable type: U/UTP (Unshielded Twisted Pair)
Cable length: 3 ft (0.91 m)
Color: Blue
Conductor: Stranded copper
Wire gauge: 24 AWG
Number of pairs: 4 pairs
Number of conductors: 8 wires
Jacket material: PVC, CM-rated (75°C)
Average cable diameter: 5.5 ± 0.3 mm
Connector type: RJ45 male to RJ45 male
Connector housing: Clear molded polycarbonate (UL 94V-2)
Contact material: Nickel-plated phosphor bronze
Contact plating: Minimum 50 µin gold
Characteristic impedance: 100 Ω ±15%
Bandwidth: 100 MHz
Data transmission speed: Up to 100 Mbps (Fast Ethernet)
Compatible with: 10BASE-T and 100BASE-TX Ethernet networks
Wiring standard: ANSI/TIA/EIA-568-C.2, ISO/IEC 11801
ETL verified and UL certified
